Treadmill Motor Controller Power Board B01007 V2.6 for Johnson T10 T21 T120 Treadmill Control Board
Couldn't load pickup availability
Treadmill Motor Controller Power Board B01007 V2.6 for Johnson T10 T21 T120 Treadmill Control Board
1 Product details:
(1) Part Number: B01007 V2.6
(2) Parcel including: 1pcs* control board
(3) Condition:new with heatsink and Test working before shipping
(4) Warranty 90days
(5) Volt:220V
2 How to determine the failed controller:
E01: communication failure, the individual is a sensor failure;
E02: controller failure, we want to know which detector is broken, if E02 is best to first test the motor to see if there are any problems motor
E03: Sensor fault; general treadmill will turn a few seconds later, there E03;
E04: generally over-current fault, this situation is generally burned components on the controller;
3 Test motor before order
Please make sure that there is no problem with the motor before you place your order.The motor can be tested by the method shown in the picture below.If the motor running smoothly by 5# battery, that means the motor is good. If running not smoothly or do not running, it means the motor broken.
4 Professional packing
5 Contact us if you need more parts
